VARIFOCAL DOME CAMERA
ACD-326SF
| FEATURES |
-
1/3" Hi-Resolution SONY Color CCD Sensor - Resolution: more than 500 TV Lines
- Auto Gain Control
- Auto White Balance
- Backlight compensation
- Auto electronic Shutter
- Varifocal Auto Iris Lens
- DC 12V
| SPECIFICATIONS |
>>ACD-326SF
[back
to top]
| ITEM No. | ACD-326SF |
| SENSOR | 1/3" SONY COLOR CCD |
| NUMBER OF PIXELS | NTSC: 768(H) x 494(V) / PAL: 752(H) x 582(V) |
| HORIZONTAL RESOLUTION | Hi-resolution, more than 500 TV line |
| SCANNING SYSTEM | 2:1 Interlace |
| SENSITIVITY ( 2700K 40IRE ) | 0.4Lux / F 1.2 |
| SYNCHRONIZATION | Internal |
| S/N RATIO | More than 48dB |
| GAMMA CORRECTION | 0.45 |
| ELECTRONIC SHUTTER | Auto and up to 1/100,000 |
| VIDEO OUTPUT | 1 Vp-p, 75 ohms load |
| LENS | 3.5mm~8.0mm Varifocal Auto Iris Lens. |
| POWER SUPPLY | DC 12V (-/+10%) |
| POWER CONSUMPTION | 110mA |
| AUTO WHITE BALANCE | MCT-AWB (MULTI COLOR TEMPERATURE |
| AUTO GAIN CONTROL | Full automatic control |
| BACK LIGHT COMPENSATION | Full automatic control |
| DIMENSION HxD mm | 86mm x 106mm |
| NET WEIGHT | 240g |
| STORAGE TEMPERATURE | -30 to +60 degree C |
| OPERATING TEMPERATURE | -10 to +45 degree C |
